| 설치 위치: | 단일 파일: 평지, 불규칙한 지형 | 프로필 자료: | Q235B(용융 아연도금)/S350GD아연-알루미늄-마그네슘 |
|---|---|---|---|
| 부가적 재료: | Q235B(용융 아연도금)/S350GD 아연-알루미늄-마그네슘 | 패스너 재료: | 8.8등급(용융 아연도금)/SUS304 스테인레스 스틸 |
| 패널 레이아웃: | 디자인 요구 사항에 따라 | 풍하중: | 60m/s |
| 강조하다: | ground-mounted solar panel structure,steel solar panel mounting system,solar panel steel support frame |
||
| Optional Materials | Zinc-aluminum-magnesium and hot-dip galvanized steel. |
| Sturdy Structure | Strong resistance to corrosion. |
| Compatibility | Compatible with both cement foundations and spiral ground piles, optimized for different terrains,and suitable foruneven surfaces. |
| Minimal Installation Parts | Pre-assembled components,saving construction time. |
| Customizable | Adjustable tiltangle and ground clearance based on actual needs. |
Technical Parameters
| Installalion Location | Single pile:Flat ground,irregularterrain Double vertical posts:Flat ground,areas with large external loads |
| Profile Material | Q235B(hot-dip galvanized)/S350GD zinc-aluminum-magnesium |
| Accessory Material | Q235B(hot-dip galvanized)/S350GD zinc-aluminum-magnesium |
| Fastener Material | Grade 8.8(hot-dip galvanized)/SUS304 stainless steel |
| Panel Layout | According to design requirements |
| Wind Load | 60m/s |
| Snow Load | 3.6kN/m² |
| Applicable Modules | Framed/framelessmodules |
| Module Layout | Vertical/Horizontal |
| Installation Angle | 0-45° |
| Warranty | 10years |
| Service Life | 25 years |
